Factory-direct OEM & ODM production lines supplying high-performance window and door systems for residential, commercial, and hospitality projects globally.
Decades of continuous innovation in premium custom fenestration manufacturing.
Aluminium Tilt and Turn window systems represent the pinnacle of modern European architectural glazing, combining dual-action operational versatility with supreme structural integrity, weather-tightness, and thermal performance. Designed to fulfill the stringent requirements of contemporary commercial facades, multi-family residential towers, and ultra-low energy luxury villas, custom OEM aluminium tilt and turn windows offer unparalleled operational flexibility: tilting inward at the top for secure, draft-free ventilation, or swinging inward completely like a casement door for full clearance and effortless interior cleaning.
As a premier OEM/ODM manufacturer headquartered in Foshan, China's hardware and extrusion epicenter, Doorreme Aluminum Industry Co., Ltd. leverages a 123,000 square meter smart manufacturing plant to deliver fully integrated custom window systems engineered to exact project specifications, architectural shop drawings, and international building compliance standards (including North American NFRC/AAMA, Australian AS2047, and European CE standards).
The structural backbone of any high-performance tilt & turn window lies in its extrusion profile geometry and alloy temper. Doorreme utilizes high-precision EN AW-6063-T6 architectural aluminium extrusions, engineered with wall thicknesses ranging from 1.4 mm for standard residential installations up to 2.0 mm+ for heavy-duty commercial applications subject to elevated wind pressure zones.
6063-T6 alloy delivers an ultimate tensile strength of ≥205 MPa and yield strength of ≥180 MPa, ensuring zero structural deflection under extreme gust pressures up to structural rating DP65 or higher.
Engineered with 24mm to 34mm PA66-GF25 (25% glass fiber reinforced polyamide) thermal break strips, effectively eliminating thermal bridging between external and internal extrusions.
Corner joints are mechanically crimped with cast aluminum corner keys and injected with two-component structural epoxy sealant, achieving permanent water-tightness and frame squareness.
By tailoring frame depth, thermal barrier width, and insulating glass unit (IGU) configurations, OEM clients can optimize U-factors, Solar Heat Gain Coefficients (SHGC), and Sound Transmission Class (STC) ratings according to micro-climate demands.
| Performance Series | Frame Depth | PA66 Thermal Strip | Glass Configuration | U-Factor (W/m²K) | STC Acoustic Rating |
|---|---|---|---|---|---|
| Series 65 Eco-Thermal | 65 mm | 20 mm | 5mm + 12A + 5mm Double Low-E | 1.8 - 2.1 W/m²K | STC 34 dB |
| Series 75 Premium OEM | 75 mm | 28 mm | 6mm Low-E + 16Ar + 6mm Toughened | 1.3 - 1.6 W/m²K | STC 38 dB |
| Series 90 Passive House | 90 mm | 34 mm + Aerogel | 5mm Low-E + 12Ar + 5mm + 12Ar + 5mm Triple | 0.79 - 1.0 W/m²K | STC 44+ dB |
| Series 108 Hurricane Impact | 108 mm | 30 mm Reinforced | 6mm + 1.52PVB + 6mm + 14A + 6mm Laminated | 1.2 - 1.5 W/m²K | STC 42 dB |
Unlike conventional push-out casements or sliding units that rely on single-point latches, Doorreme OEM Tilt & Turn systems utilize continuous perimeter gear transmission hardware supplied by tier-one German partners (such as Roto Frank, Siegenia, or Hoppe) alongside premium proprietary Doorreme hardware systems. When the handle is rotated down to 0°, multiple mushroom cam locks engage with heavy-duty steel strike plates positioned along all four sides of the frame. This creates uniform perimeter compression against triple continuous EPDM (Ethylene Propylene Diene Monomer) weather gaskets, achieving supreme air barrier tight seal and RC2/RC3 burglar resistance ratings.
Analysis of changing procurement criteria, building energy mandates, and technological innovations shaping the global fenestration supply chain over the next decade.
Global procurement officers and real estate developers are demanding verified Environmental Product Declarations (EPDs). Sourcing trends favor suppliers utilizing hydro-powered smelting processes and post-consumer recycled aluminum billets (reducing embodied carbon from 18 kg CO₂/kg Al down to under 4.0 kg CO₂/kg Al).
Modern architectural aesthetics emphasize maximum glass area and clean interior surfaces. Demand is shifting rapidly toward fully concealed tilt & turn hinge systems integrated within the sash profile rebate, eliminating visible hardware while accommodating heavier glazing weights up to 180 kg per sash.
Commercial office towers and automated high-end residences are embedding smart mechatronic drive units within the window frame. These concealed electric actuators connect with Central Building Management Systems (BMS) for automated night purge cooling, indoor air quality (CO₂) sensor triggering, and rain sensor closure.
International buyers are increasingly bypassing intermediary sourcing agents to establish direct engineering partnerships with specialized OEM factories capable of supplying synchronized packages: matching tilt & turn windows, unitized curtain walls, structural glass railings, and entrance doors from a single quality control source.
Founded in 2004, Doorreme has grown from a specialized fabrication shop into a global leader in engineered aluminium fenestration systems. Here is how our production ecosystem guarantees project success for developers, contractors, and importers:
Equipped with imported German Elumatec CNC profile processing centers, double-head precision cutting saws, and automated insulated glass line assembly, guaranteeing fabrication tolerances within ±0.5 mm.
Over 50 in-house facade engineers provide 2D shop drawings, 3D BIM models, structural finite element calculations, and thermal modeling (LBNL THERM/WINDOW) prior to manufacturing release.
Raw materials undergo rigorous incoming quality control (IQC), anodizing/PVDF coating thickness testing (ISO 2360), in-process water tightness testing, and pre-shipment container trial assembly.
Exporting to over 140 countries, our packaging standard features protective film wrapping, corner guards, fully enclosed fumigated wooden crates, and steel frame container rack loading.
Clear, technical answers to common questions raised by architects, facade consultants, procurement heads, and real estate developers.
Connect directly with Doorreme's senior engineering team for technical evaluations, instant factory-direct quotations, and sample requests.
