Direct OEM manufacturing from our Foshan facility. Standard and thermal break profiles precision-engineered to project blueprints, architectural specs, and international building codes.
Modern commercial and residential architectural designs demand high window-to-wall ratios to maximize daylighting and unobstructed views. As a premier custom OEM aluminum horizontal sliding windows manufacturer based in Foshan, China, Doorreme Aluminum Industry Co., Ltd. engineered advanced fenestration profiles that balance aesthetic minimalist sightlines with robust structural load capacities.
Horizontal sliding windows operate on a lateral track system, transferring structural dead load directly to the lower sill profile while accommodating severe lateral wind loads ($W_p \ge 3.0\text{ kPa}$). Our structural extrusions utilize primary high-purity 6063-T5 and 6063-T6 architectural grade aluminum alloys with profile wall thicknesses ranging from 1.2mm for standard multi-family housing up to 2.0mm+ for heavy-duty commercial storefront applications.
| Window Series | Wall Thickness | Glazing Pocket | Thermal Barrier | Max Panel Height | Target Application |
|---|---|---|---|---|---|
| DR-SL80 Economy | 1.2 mm - 1.4 mm | 4mm+12A+4mm Double Glazed | Non-Thermal / Optional PVC | 2200 mm | Standard Residential & Multi-Family |
| DR-SL100 Thermal Break | 1.4 mm - 1.6 mm | 5mm+18A+5mm Low-E Argon | 24mm PA66-GF25 Polyamide | 2800 mm | High-End Villas & Green Buildings |
| DR-SL120 Heavy-Duty | 1.8 mm - 2.0 mm | 6mm+20A+6mm / Laminated | 30mm PA66-GF25 Multi-Chamber | 3500 mm | Coastal Wind Zones & High-Rises |
| DR-SL150 Ultra-Slim | 2.0 mm - 2.5 mm | 8mm+16A+8mm Triple Low-E | Integrated Structural Thermal | 4000 mm | Luxury Commercial & Storefronts |
Founded in 2004, Doorreme Aluminum Industry Co., Ltd. operates a state-of-the-art 123,000 m² integrated production base in Foshan, China. We combine European extrusion engineering with rigorous quality control.
Equipped with automated Italian and German CNC processing machinery, double-head precision miter saws, and automatic corner-crimping lines, delivering 500,000 m² of certified fenestration products annually.
Our horizontal sliding window systems strictly comply with global architectural standards including North American NFRC/AAMA, Australian AS2047 / AS1288, Canadian CSA, and European CE standards.
From customized profile dies and thermal break chamber design to specialized anodizing, PVDF fluorocarbon spraying, and custom hardware integration (German Roto/Siegenia or top-tier OEM options).
The fenestration sector is experiencing radical technological shifts driven by stringent building energy codes, modern architectural aesthetics, and smart home automation demands.
Architects are moving away from bulky 80mm-100mm vertical interlock stiles. Next-generation horizontal sliding windows utilize reinforced ultra-slim vertical stiles as narrow as 20mm to 28mm, embedded with concealed structural steel or carbon fiber stiffeners to retain structural wind load rating while maximizing visual transparency.
With passive house standards gaining global traction, modern sliding window profiles integrate multi-chamber polyamide PA66-GF25 thermal struts combined with expanded Polypropylene (EPP) insulation foam inserts, dropping profile thermal conductivity ($U_f$) below $1.5\text{ W/m}^2\text{K}$.
Traditional weeping holes are being replaced by hidden stepped-down subterranean drainage systems featuring non-return check valves to eliminate air infiltration during high-pressure typhoons. Furthermore, motorized linear-drive actuators allow smartphone and home automation control for automated sliding operation.
Global real estate developers, contractors, and fenestration distributors face tightening energy efficiency mandates, fluctuating shipping costs, and changing supply chain dynamics. Sourcing custom OEM aluminum horizontal sliding windows requires a forward-looking procurement strategy:
In-depth technical answers for window distributors, project architects, and procurement managers sourcing from our OEM factory.
Partner with Doorreme Aluminum Industry Co., Ltd. for factory-direct wholesale pricing, precision engineering, and certified export quality. Submit your architectural blueprints or window schedules today.
