Explore our factory-direct single door series, custom casement units, bifold configurations, and high-performance architectural systems designed for international project specifications.
As global building codes demand higher acoustic damping, thermal decoupling, and structural wind-load capacity, the engineering requirements for commercial and residential single aluminum entry doors have scaled significantly. OEM (Original Equipment Manufacturer) and ODM (Original Design Manufacturer) partnerships present global project contractors, real estate developers, and wholesale distributors with the exact custom specs required to bridge architectural vision and stringent local compliance.
High-grade single door systems rely primarily on architectural-grade EN AW-6063-T6 or 6060-T66 extruded aluminum alloys. Tensile strength (≥205 MPa) and yield strength (≥170 MPa) are calibrated via controlled artificial aging processes. Wall profile thickness ranges from 1.6mm for heavy-duty entry single hinged doors up to 3.0mm for high-traffic commercial glass swing doors.
Incorporating polyamide 66 reinforced with 25% glass fiber (PA66-GF25) thermal break strips reduces thermal conductivity through the frame. In combination with Low-Emissivity (Low-E) double-glazed or triple-glazed argon-filled insulating units ($4\text{mm} + 12\text{A} + 4\text{mm}$ to $5\text{mm} + 20\text{A} + 5\text{mm}$), single door configurations can achieve overall U-factors down to $1.2 \text{ W/m}^2\text{K}$, compliant with NFRC, CE, and Energy Star requirements.
Standard parameters utilized by our engineering team to construct custom single entrance, French, pivot, and side-hung exterior aluminum doors.
| Performance Standard | Technical Baseline / Specification | OEM Customization Options | Applicable Certifications |
|---|---|---|---|
| Profile Alloy & Temper | Aluminum Alloy 6063-T5 / T6, 6060-T66 | 6005A-T6 high-structural reinforcement alloy | GB/T 5237, EN 755 |
| Profile Wall Thickness | 1.4mm - 2.0mm (Standard Residential), 2.5mm - 3.0mm (Commercial) | Custom structural mullion reinforcement up to 4.0mm | ASTM B221, ISO 9001 |
| Thermal Insulation (U-Value) | $1.4 - 2.2 \text{ W/m}^2\text{K}$ (Standard Thermal Break Profile) | Aerogel-filled profile insulation ($U_w \le 0.9 \text{ W/m}^2\text{K}$) | NFRC 100/200, ISO 10077 |
| Surface Treatment | Powder Coating (60-80µm), Anodized (Class 15-25µm) | Fluorocarbon PVDF (2/3-coat), AkzoNobel Interpon, Wood-grain transfers | AAMA 2604, AAMA 2605, QUALICOAT |
| Glazing Architecture | 5mm + 12A + 5mm Double Tempered Insulated Glass | Laminated Low-E (5mm+1.14PVB+5mm), Bullet-Resistant, Acoustic Glass | SGCC, EN 12150, AS/NZS 2208 |
| Hardware & Security | Multi-Point Locking System, Heavy-Duty Stainless Steel Hinges | German Roto / HOPPE / Siegenia, Smart Biometric Locks, Hidden Pivot Hinges | EN 12209, PAS 24, BHMA Grade 1 |
| Wind Pressure Resistance | Class C5 (ASTM E330 wind load test up to 5000 Pa) | Florida Hurricane Impact Certification (HVHZ approved) | TAS 201/202/203, ASTM E1886 |
Operating from a 123,000 m² modern manufacturing facility in Foshan, China, Doorreme Aluminum Industry Co., Ltd. provides complete facade and door solutions backed by over two decades of engineering excellence.
Equipped with German Elumatec CNC machining centers, automated corner-crimping systems, and precision cutting tools, enabling a massive 500,000 m² annual production capacity with micro-level dimensional tolerances.
Our dedicated engineering team reviews client CAD files, structural wind pressure requirements, and shop elevation drawings to deliver customized section details, ensuring flawless site assembly and code sign-off.
From high-rise commercial towers in North America to luxury resort villas in the Caribbean and Oceania, our robust export packaging (EPE foam wrap + wooden crate framing) ensures damage-free global freight arrival.
As commercial procurement transitions toward circular economy compliance and smart structural design, architectural single door sourcing is shifting toward several core innovations.
Environmental regulations (such as the EU's CBAM carbon boundary adjustment) are pushing major procurement teams to require certified post-consumer recycled aluminum content. Using hydro-powered remelted aluminum billets drops embodied carbon emissions from $18\text{kg CO}_2\text{/kg Al}$ down to under $4.0\text{kg CO}_2\text{/kg Al}$ without sacrificing mechanical yield metrics.
Architectural demand for maximum natural daylighting has accelerated the development of hidden-frame single doors and concealed pivot hinges. Modern single hinged glass doors utilize profile face widths under 45mm while maintaining glass load ratings exceeding 250 kg per door leaf through high-modulus structural silicone bonding.
OEM specifications increasingly integrate multi-modal electronic access directly inside the aluminum stile. Multi-point motorized locks, embedded wiring channels for facial recognition systems, and magnetic lock sensors are now standard OEM options requested by hotel operators and luxury residential builders.
For coastal and high-humidity environments, standard powder coatings are rapidly being replaced by 70% Kynar 500 / Hylar 5000 PVDF finishes meeting AAMA 2605 specifications. These chemical barrier coatings withstand over 4,000 hours of continuous salt spray testing without blistering or chalking.
Real-world commercial and hospitality projects engineered and supplied from our Foshan production hub.
Location: Santa Cruz, Bolivia
Scope: 14,000 m² glazed curtain wall, customized single access doors, and 4,300 m² skylights with complex structural wind load sign-offs.
Location: Banjul, Gambia
Scope: High-traffic commercial entrance single doors, heavy-duty aluminum composite panel facades, and Low-E solar control insulated glazing units.
Location: Dominica, Caribbean
Scope: 1,500 m² hotel project featuring coastal-grade PVDF finished single patio doors, thermal break awning windows, and hurricane-resistant glass railings.
Technical and logistics answers for architectural specifiers, contractors, importers, and OEM brand buyers.
Submit your project drawings, door schedules, or wholesale procurement requirements today. Our senior engineering team will provide comprehensive section details, structural load feedback, and factory-direct pricing within 24 hours.
