Custom-engineered fenestration solutions exported direct from our 123,000 m² factory base to Barcelona project sites.
An authoritative analysis on balancing industrial heritage aesthetic with strict Mediterranean thermal envelope standards (CTE DB-HE).
The architectural landscape of Barcelona and the broader Catalonia region is undergoing a profound material synthesis. From the iconic grid-patterned apartment blocks of the Eixample district to the converted industrial warehouses of Poblenou (22@ tech zone) and coastal villas in Sitges and Maresme, modern architectural intent demands ultra-slim, steel-inspired sightlines paired with uncompromised thermal efficiency. The iconic "Crittall style"—historically rendered in heavy hot-rolled steel—has been completely re-engineered by leading Chinese extrusion factories through advanced thermally broken architectural aluminium (6063-T6 alloy).
As a certified enterprise exporter supplying developer, architectural, and contractor networks across 140+ countries, Doorreme Industry provides the technical foundation required to integrate modern steel-look external aluminium doors into Spain’s stringent regulatory frame. Unlike original steel glazing systems, which suffer from severe thermal bridging and oxidation when exposed to Barcelona’s humid Mediterranean maritime air, engineered aluminium Crittall systems deliver exceptional durability, lower structural weight, and thermal transmittance values (Uw values down to 1.2 W/m²K) compliant with Spain’s Código Técnico de la Edificación (CTE DB-HE).
Why modern Catalan architects and developers are substituting traditional steel profiles with architectural aluminium extrusions.
| Performance / Engineering Parameter | Traditional Hot-Rolled Steel Crittall | Doorreme Thermally Broken Aluminium Crittall | Impact on Barcelona Projects |
|---|---|---|---|
| Thermal Insulation (Uw Value) | 3.5 – 5.2 W/m²K (High thermal bridging) | 1.2 – 1.6 W/m²K (PA66 Polyamide Break) | Full compliance with Spanish CTE DB-HE Climate Zone C2/C3 regulations. |
| Coastal Marine Corrosion Resistance | Prone to rust at weld joints within 3–5 years without frequent galvanizing upkeep. | Qualicoat Class 2 Powder Coat / PVDF Finish (Passes 2,000h Salt Spray Test). | Essential for coastal humidity in Barceloneta, Badalona, Sitges, and Costa Brava. |
| Structural Weight & Installation | Heavy structural load (~45-60 kg/m²), requiring reinforced sub-frames. | Optimized Strength-to-Weight Ratio (~22-32 kg/m²). | Reduces structural dead load on historical Eixample floor slabs (Catalan vaults). |
| Acoustic Performance (Rw) | Typically Rw 24-28 dB with single glazing. | Up to Rw 42 dB with Double/Triple Acoustic Laminated Glass. | Blocks urban noise pollution from traffic along Gran Via, Diagonal, and Avinguda Meridiana. |
| Design Customization & Grid Flexibility | Rigid manual steel welding; costly custom mullion profiles. | Precision CNC Applied Glazing Bars & True Divided Lites. | Replicates historic Catalan steel grid patterns while maintaining acoustic integrity. |
Tailored fenestration solutions engineered for specific urban micro-climates and architectural typologies.
Historic apartments along Rambla de Catalunya and Enric Granados feature quiet inner courtyard gardens. Our slim-profile exterior French doors with black Crittall grids allow maximum natural light into interior living areas while meeting local heritage conservation guidance for rear facade retrofits.
Former textile mills transformed into modern tech headquarters and luxury lofts demand authentic industrial aesthetic. We supply floor-to-ceiling multi-panel aluminium Crittall sliding systems and pocket doors that transition internal workspace directly to outdoor terraces.
Luxury residential properties exposed to direct sea mist require ultimate marine-grade protection. Our doors feature PVDF fluoropolymer 3-coat finishes, 316 stainless steel multipoint locking hardware, and high-performance Low-E solar control double glazing to reflect Mediterranean heat.
For high-end residential estates requiring integrated automation and smart home ecosystems, we export wide-format Crittall swing and pivot doors equipped with motorized smart locks, concealed hinges, and thermal-break threshold tracks flush with internal flooring.
Direct technical compliance for Spanish architectural specifications and environmental directives.
In Catalonia, any building envelope modification—whether new build or energy renovation—must conform strictly to the Código Técnico de la Edificación (CTE), specifically DB-HE 1 (Limitation of energy demand). Barcelona falls within climate zone C2 for coastal areas and C3 for inland hill areas like Collserola.
Profile Alloy: High-precision extruded 6063-T6 architectural aluminium frame.
Thermal Barrier: Technoform 24mm - 34mm PA66 polyamide insulation strips.
Surface Treatment: AkzoNobel Interpon powder coat / PVDF fluoropolymer (60-80 microns depth).
Hardware Integration: German Siegenia / Roto multipoint locking systems; optional hidden hinges.
Glazing Configuration: 28mm to 44mm Double/Triple insulated units with warm-edge spacers & Argon gas fill.
Essential guidance for Spanish architects, main contractors, importers, and private villa developers.
We apply architectural-grade PVDF (polyvinylidene fluoride) or Qualicoat Class 2 powder coating finishes over a multi-stage pre-treatment wash. This surface system passes over 2,000 hours of continuous acetic acid salt spray (AASS) testing (ISO 9227), completely preventing blistering, chalking, or aluminum oxide corrosion common in maritime regions like Barceloneta, Maresme, or Sitges.
Yes. Every external door unit produced by Doorreme is tested to European Norms (EN standards). We provide full CE declaration of performance (DoP) documents covering structural wind resistance (UNE-EN 12210), air permeability (UNE-EN 12207), water tightness (UNE-EN 12208), and acoustic attenuation, allowing seamless sign-off by your local municipal *Arquitecto Técnico* (Technical Architect).
All items are wrapped in protective polyethylene film, fitted with corner guards, and packed inside fully sealed ISPM-15 compliant fumigated plywood crates. Shipments are loaded directly into 20GP or 40HQ ocean containers in Foshan and shipped to the Port of Barcelona (Puerto de Barcelona / ZAL). We support FOB, CIF, or full DDP (Delivered Duty Paid) door-to-door delivery right to your job site in Catalonia.
Upon receiving site opening dimensions or CAD architectural elevation drawings, our engineering team issues final production CAD drawings within 48 hours. Manufacturing takes 25–35 days depending on profile finish (custom RAL colors). Ocean transit from South China ports to the Port of Barcelona typically requires 28–32 days. We advise factoring a total timeline of 8–10 weeks from deposit to site arrival.
We manufacture both configurations. For maximum thermal performance and ease of maintenance, Simulated Divided Lites (SDL) with internal space bars and exterior aluminium grids are recommended for external doors. However, True Divided Lites (TDL) can be engineered for individual insulated glass units where architectural heritage specifications demand distinct glass pane division.
Direct-from-factory engineering capability eliminating middleman markups for major European projects.
Located in Shishan Town, Foshan—China’s premier aluminium processing capital—our state-of-the-art facility features fully automated Italian Elumatec CNC machining centers, automated cutting saws, and precision assembly lines producing over 500,000 m² of fenestration systems annually.
Our engineering division employs over 80 structural engineers and CAD draughtsmen dedicated to wind load modeling, structural silicone glazing (SSG) calculations, thermal simulation analysis (using LBNL THERM software), and custom extrusion die design.
Operated under strict ISO9001:2015 quality standards, every assembly step undergoes multi-point inspection—from raw 6063-T6 billet hardness testing and anodizing film thickness measurement to 100% water tightness testing on finished door sashes prior to export packaging.
Whether you are renovating an Eixample apartment, developing a luxury Poblenou loft complex, or designing a coastal villa in Sitges, our technical engineering team is ready to review your elevation drawings and provide instant factory-direct pricing.
